Have queries on this Project?
28.56104
77.48526
Showing 8 blocks with 298 units
Total Carpet Area
87675.30 m²
943728.16 ft²
Total Units
750
4 different types
Blocks & Floors
8
35 floors across all blocks
Parking
0
0 garages, 0 open
No: Regn No. 38039, Book No. 1, Volume 28104, Page from 113 to 164 | Date: 20-07-2024
Total Area
30000.00 m²
322917.00 ft²
OTHER PROPERTY OF MY LAAGOON ON SOUTH-WEST AND NORTH-WEST SIDE AND 24M. WIDE ROAD ON SOUTH-EAST AND NORTH-EAST SIDE OF THE PLOT.
1800MM HIGH BOUNDARY WALL IN COMBINATION OF RCC FOUNDATION AND BRICK/ M.S. GRILL PROVIDED ALONG 3 SIDES OF THE PLOT.
7.5M WIDE INTERNAL ROAD ALL AROUND THE BUILDING DESIGNED TO TAKE THE LOAD OF FIRE TENDER MOVEMENT.
FOOT PATH HAS BEEN PROVIDED AS PART OF THE 6M WIDE DRIVEWAY FOR FIRE TENDER.
WATER SUPPLIED FROM MY LAAGOON WILL BE STORED IN DOMESTIC WATER TANK (UGT) OF CAPACITY 370KL AND OHT, AND THEN WILL BE SUPPLIED TO THE RESPECTIVE UNITS AS PER ATTACHED MAP.
ADEQUATE SEWER LINES WILL BE PROVIDED WHICH WILL DISCHARGE SEWAGE TO THE CENTRALISED STP OF MY LAAGOON, AS PER ATTACHED MAP.
STORM WATER DRAINAGE SHALL BE PROVIDED AND WILL BE CONNECTED TO THE RAINWATER HARVESTING PITS AS PER ATTACHED MAP.
REQUIRED GREEN AREAS HAS BEEN PROVIDED IN MY LAAGOON MASTER PLAN. SO IT IS NOT APPLICABLE FOR THIS COMMERCIAL PLOT.
A VARIETY OF GREEN TREES WILL BE PROVIDED AS PER SANCTION PLAN.
TO CATER THE DEMAND ELECTRICAL LOAD, INCOMINGT POWER IS AVAILABLE FROM 11KVA LINE, SUBSTATION IS PLANNED WITH 2 NOS OF 2000 KVA TRANSFORMER, 1 NO OF 1000 KVA TRANSFORMER AND 1 NO OF 500 KVA TRANSFORMER . ADEQUATE STREET LIGHTING WILL BE PROVIDED WITH LED LIGHTS.
THE CLUB HOUSE SHALL BE PROVIDED WITH GYMNASIUM AND FITNESS CENTER, GAMING ZONE, MULTIPURPOSE HALL.
SEWER WATER COLLECTED IN THE BUILDING WILL BE TREATED AT THE CENTRAL STP AT MY LAAGOON TOWNSHIP.
THE ORGANIC WASTE AS COLLECTED FROM THE PROJECT WILL BE TREATED IN THE ORGANIC WASTE CONVERTER OF CAPACITY 300 KG/ DAY INSTALLED AT SITE.
9 NO.S OF RWH WILL BE PROVIDED AT SITE FOR GROUND WATER RECHARGE. LOW FLOW WATER FICTURES WILL BE PROVIDED FOR WATER CONSERVATION.
SOLAR PANELS WILL BE PROVIDED AT ROOF TOP TO GENERATE RENEWABLE ENERGY.
FIRE SPRINKLERS, SMOKE DETECTORS, FHC WITH PUMP, ARE PROVIDED AS PER NORMS.
TOILETS FOR DIFFERENTLY ABLED PEOPLE, DRINKING WATER FACILITIES, FIRST AID FACILITY WILL BE PROVIDED.
REQUIRED NO. OF FIRE STAIRCASES, EXIT DOORS, AND DIRECTIONAL SIGNAGES WILL BE PROVIDED IN THE BUILDING AS PER APPROVED FIRE PLANS.
AS PER APPROVED LAYOUT AND REQUIREMENTS.
