Launch Date
RERA Received Date
Completion Date
Configurations
Sizes
Total Floors
RERA ID
28.505273
77.384313
Number of plots - 1 No Size per plot - 22504.57 Sqm total area demarcated Method of demarcation, Survey accuracy - As per Site plan and Possession Plan.
Length - 617.537Mtr, height - 2.1mtr, Material used type (brick, RCC, fencing) - RCC, Brick, MS Appearance - As per Elevation, Safety features - CCTV
Total road Length - 846.513Rmt , and width - 9mtr, Number of lanes - 2 Way, Type of pavement - RCC , drainage, Surface durability - As per fire tender movement.
Length - 881.9544mtr, Width - 1.6mtr, Number of crossings - 17 Nos, Material used - Pavers tiles,
Connections - 1 no, tank capacity - domestic water tank - 390 KLD, fire water tank - 570 KLD, hydrants - yes provided, source of water - municipal water supply, water treatment method - water treatment using dual media and activated carbon filters, compliance with quality standards - yes
Length of sewer lines - pipes are running in basement ceiling by gravity, pipe size - 160 mm dia manholes type (gravity / pressure ) provision of manholes has not been proposed as the pipe is running in basement at ceiling level by gravity, network design - piping network.
Length - 604.287mtrs, width - 500 mm dia (dia of pipe) number of open / covered drains, type (storm / surface) storm water system is planned usung pipe system, pipe material - SN4 disposal method - using rainwater harvesting and external drain.
Area - 4913.5732 Sqm , Number of parks - 01 Nos Number of trees / plants - 113 Nos, Landscaping features, Types of parks, Public amenities - NA
Number of trees - 113 Nos, Types / species - 2 Type, Spacing - 5mtr , Native / exotic trees - native trees, maintenance plan - yes,
Number of external poles / lights - approx. 45 Nos, transformer units - 3 Nos, (Capacity of 2 Nos. 1600 KVA and 1 No. 1250 KVA) Type of lighting ( LED / solar ) LED, lllumination design - yes as per norms.
Number - 01 Nos, Capacity - 1862 Nos, Area per building - 2846.581 Sqm construction type - RCC, brickwork and MS, facilities - as proposed plan
STP capacity (KLD) - 310 KLD , number of treatment units - 1 No, type of STP - moving bed biofilm reactor (MBBR) technology, treated water use - flushing, horticulture regulatory compliance - yes as per norms.
Water generated - 1.58 TPD wastes including Approx. 0.95 TPD biodegradable wastes
Number and size of harvesting pits - 16 Nos. of 30 m3 capacity each. recharge wells - yes provided, water - efficient fixtures - considered low flow sanitary fixtures, reuse / recharge strategy - rain water will be used for ground water recharge , system effciency - as per norms.
Online solar power system of capacity 35 KWP.
Number of hydrants - 14 Nos. (external) more than 100 hydrants internal, sprinklers , system type ( manual / automatic)- automatic, NBC compliance - yes fire safety training - will be provided at the time of occupancy.
Number / area of amenities ( toilets) - 06 Nos Type of services offered , inclusiveness , accessibility provided - NA
Number of evacuation points - 12 Nos, road widths - 9.0mtr. signage count - yes , route plan - yes safety measures - yes public awareness system - yes
Work based on the nature of work ( e.g. number of CCTV units benches) beautification efforts, signage , aesthetic and utility elements CCTV proposed as per project requirement .
Showing 6 blocks with 192 units
Total Carpet Area
63220.52 m²
680499.36 ft²
Total Units
500
2 different types
Blocks & Floors
6
32 floors across all blocks
Parking
0
0 garages, 0 open
Total Area
22504.00 m²
242230.81 ft²
