M3M The Cullinan II
Overview
Launch Date
Completion Date
Project Size
Total Floors
RERA ID
Basic Details
Location
28.55028333
77.32824444
Brochures
Walkthrough
Bank Details
Development Works
Demarcation of Plots
Number of plots- 1 No, Size per plot- 52035 Sqm, total area demarcated, method of demarcation, survey accuracy- As per site plan and possession plan.
Boundary Wall
Length- 930 Mtr, height- 1.5 Mtr, material used, type (brick, RCC, fencing) - RCC and Brick, appearance - As per Elevation, safety features - CCTV
Road Work
Total road Length - 861.30 Rmt., and width - 9 Mtr, number of lanes - 2 Way, type of pavement - RCC, drainage, surface durability - As per Fire Tender Movement.
Footpaths
NA
Water Supply Including Drinking Water Facilities
Connections -1 No, Tank capacity - Domestic water tank - For Residential 360 KLD and for Commercial 500 KLD, Fire Water Tank- 1155 KLD, Hydrants - Yes Provided, Source of Water - Municipal water supply, water treatment method - Water Treatment using dual media and activated carbon filters, Compliance with quality standards- Yes
Sewer System
Length of sewer lines - Pipes are running in basement ceiling by gravity, pipe size - 160 mm dia, Manholes type (gravity/pressure) - provision of manholes has not been proposed as the pipe is running in basement at ceiling level by gravity, Network design - Piping network.
Drain
Length - 585 mtrs, Width - 500 mm dia (Dia of pipe), Number of open/covered drains, type (storm/surface)- storm water system is planned using pipe system, Pipe Material - SN4, Disposal method - using rainwater harvesting and external drains.
Parks
NA
Tree Planting
Number of trees - 236 Nos , type/species-2 type, spacing- 5 mtr, native/exotic trees - Native Trees, maintenance Plan- Yes.
Design For Electric Supply Including Street Lighting
Number of External poles/lights - Approx. 45 Nos, Transformer units - 7 Nos, Type of lighting (LED/solar) - LED, Illumination design - Yes as per norms.
Community Buildings
Proposed as per 4th Floor Plan.
Treatment and Disposal System of Sewage and Sullage water
STP capacity (KLD) - 1190 KLD, Number of treatment units - 1 No , type of STP - SBR, Treated water use - Flushing, horticulture and HVAC cooling tower, Regulatory compliance - Yes As per norms.
Solid Waste Management And Disposal System
Waste generated (Kg/Day) - 4932 Kg/day
Water Conservation System
Number and size of harvesting pits - 13 Nos. of 65 m3 capacity each, recharge wells - Yes Provided, Water - efficient fixtures - considered low flow sanitary fixtures, Reuse/recharge strategy - rain water will be used for ground water recharge, system efficiency - As per Norms.
Energy Management System Including Use of Renewable Energy
Online Solar power system of capacity 318 KWp.
Fire Protection And Fire Safety System
Number of hydrants - 20 Nos. (External), more than 100 Hydrants internal, Sprinklers, system type (manual/automatic)- Automatic , NBC compliance - Yes, fire safety training- will be provided at the time of occupancy.
Social Infrastructure And Other Public Amenities Including Public Health Services
NA
Emergency Evacuation Services
19 Nos, road widths - 9.0 Mtr., signage count - yes, route plan- Yes, safety measures - Yes, public awareness system - Yes
Other Miscellaneous Work
Beautification efforts, signage, aesthetic and utility elements CCTV proposed as per project requirements
Documents
Other Plan(If Any)
Other Plan(If Any)
Proforma of Completion Certificate(Occupancy)
CA CERTIFICATE
Permits
Project Team
Land Details
Showing 4 blocks with 399 units
Property Summary
Total Carpet Area
58280.07 m²
627320.85 ft²
Total Units
408
3 different types
Blocks & Floors
4
47 floors across all blocks
Parking
0
0 garages, 0 open
Block Tower C2
41 unitsBlock Emporium
188 unitsBlock Tower D1 (Trump Tower)
85 unitsBlock Tower D2 (Trump Tower)
85 unitsKhasra Details
Total Area
5830.00 m²
62753.54 ft²
