M3M J and C
Overview
Launch Date
Completion Date
Project Size
Total Floors
Launch Price
RERA ID
Basic Details
Location
28.32928
77.211716
Brochures
Bank Details
Development Works
Demarcation of Plots
1 Plot of 23570.92 Sqm., NW Side 30 meters wide Road, SW side 45 meters wide road, SE side 45 meters wide road, NE side other plot.
Boundary Wall
Length- 659.16 Mtr, height- 1.5 Mtr, material used, type (brick, RCC, fencing), RCC and Brick, appearance- as per elevation, safety features-CCTV
Road Work
Total Road Length, 566Rmt, and width 6.0 to 7.5 Mtr., number of Lanes-2 way. All roads in the complex will be a combination of Trimix, concrete pavers of different colours, shapes, and thickness. Roads will be laid over 225 mm water-bound macadam.
Footpaths
All footpaths in the complex will be a combination of concrete pavers of different colours, shapes, and thickness of 65 mm and 80 mm laid over a 150 mm water-bound macadam surface.
Water Supply Including Drinking Water Facilities
1 No. , domestic water tank-500 KLD, Fire Water Tank-840KLD, Hydrants provided, Potable water supply from the municipal water supply shall be collected in an underground collection tank and pumped to an overhead water tank. The supply of water to individual Units shall be from the said overhead water tanks. Water treatment using dual media and activated carbon filters
Sewer System
The sewage will be collected through a soil pipeline arrangement, bends, and inspection chambers leading to the sewage water treatment plant (STP) of the total project, and treated water will be used for irrigation and flushing purposes. Pipes are running in the basement ceiling by gravity, pipe size-200 mm dia, manhole has not been proposed as the pipe is running in the basement at ceiling level by gravity, piping network design is used.
Drain
Length 385 mtrs., width-450 mm dia(Dia of Pipe) , storm water system is planned using pipe system, Pipe material is SN4, disposal by using rainwater harvesting and external drains.
Parks
Green area to be provided as per the approved plan.
Tree Planting
The trees will be planted at all suitable locations of the project and along the boundary walls. The tree selection, flora, and vegetation shall be as per the climatic conditions. Trees will be planted in a manner to ensure that there is no hindrance to the services/ usage in the project.
Design For Electric Supply Including Street Lighting
LED lights will be used for street lighting, approximately. 33Nos. of external poles/lights proposed, transformer units, 5 in number.
Community Buildings
The community area is within the building footprint and will be developed as per the approved plan.
Treatment and Disposal System of Sewage and Sullage water
Sewage shall be treated in the Sewage Treatment Plant (STP) of 700 KLD Capacity, type of STP- MBBR, and thereafter, the treated water shall be used for flushing and irrigation.
Solid Waste Management And Disposal System
Solid waste, approximately 2790 Kg/day, is to be collected from individual flats and stored in the garbage room. Recyclables shall be processed in the compost machine to make compost. Non-recyclable waste shall be disposed of through approved agency.
Water Conservation System
Rainwater harvesting pits , 5 in number of 45 m3 capacity each, shall be provided for groundwater recharging and overflow to be discharged in the municipal drains. Treated sewage shall be used for irrigation and flushing.
Energy Management System Including Use of Renewable Energy
A solar panel system of 135 KW will be used to reduce the energy consumption, and electrical appliances with a star rating will be used in the community building.
Fire Protection And Fire Safety System
Sprinklers, fire doors, yard hydrants, smoke detectors, and fire alarm system will be provided as applicable. 12 Nos. External and more than 100 internal hydrants shall be used.
Social Infrastructure And Other Public Amenities Including Public Health Services
Not Applicable.
Emergency Evacuation Services
Fire staircases shall be provided as per the approved fire drawing for evacuation to open areas.
Other Miscellaneous Work
Not applicable.
Documents
Other Plan(If Any)
Other Plan(If Any)
Other Plan(If Any)
Proforma of Completion Certificate(Occupancy)
Permits
Project Team
Land Details
Showing 5 blocks with 1111 units
Property Summary
Total Carpet Area
72669.30 m²
782205.08 ft²
Total Units
1561
5 different types
Blocks & Floors
5
38 floors across all blocks
Parking
0
0 garages, 0 open
Block M3M JACOB AND CO RESIDENCES/T-1
38 unitsBlock M3M JACOB AND CO RESIDENCES/T-2
42 unitsBlock M3M JACOB AND CO RESIDENCES/T-3
42 unitsBlock M3M JACOB AND CO SKYSUITES/T-4
38 unitsBlock M3M JEWEL CREST AVENUE
951 unitsKhasra Details
Total Area
23570.92 m²
253715.03 ft²
