VVIP YAMUNA
Overview
Launch Date
Completion Date
Configurations
Sizes
Project Size
Total Floors
RERA ID
Basic Details
Location
28.1905
77.3154
Layout
Payment Plans
Floor Plan
Walkthrough
Bank Details
Development Works
Demarcation of Plots
NUMBER OF PLOTS -01, SIZE PER PLOT -20235 SQM, TOTAL AREA DEMARCATED -20235 SQM, METHOD OF DEMARCATION -BY TOTAL STATION, AERIAL SURVEY AND BY YEIDA AUTHORIZED AGENCY.
Boundary Wall
BOUNDARY WALL LENGTH-580.77M, HEIGHT-2.10M, MATERIAL USED RCC+BRICK+MILD STEEL, TYPE-BRICK +RCC+FENCING.
Road Work
TOTAL ROAD LENGTH-513.73M AND WIDTH 7.50M, NUMBER OF LANES-01, TYPE OF PAVEMENT-RIGID, DRAINAGE-SURFACE DRAINS, SURFACE DURABILITY-TREMIX/ VDF CONCRETE BROOM FINISHED/PAVER BLOCKS/COBBLE STONES ON TOP.
Footpaths
NA
Water Supply Including Drinking Water Facilities
N. OF WATER CONNECTION-ONE, TANK CAP.840KLD (-570 KLD+ WATER TANK-270 KLD), HYDRANTS-200, SOURCE OF WATER -MUNICIPAL, TREATMENT METHOD-FILTRATION SYSTEM AND COMPLIANCE AS PER IS 10500
Sewer System
LENGTH-400M, DIA 250MM, MANHOLES 21, TYPE OF GRAVITY , MATRIAL-SN44 AND METHOD -AS PER MANNING FORMULA.
Drain
LENGTH- 600M, DIA 250MM, 300.MM AND 400 MM , MANHOLES 38, TYPE OF GRAVITY , MATRIAL -SN4 AND METHOD-AS PER MANNING FORMULA , DISPOSAL METHOD-RWH AND OVER FLOW TO MUNICIPAL DRAIN
Parks
AREA-10895.96 SQM, NUMBER OF TREES /PLANTS-160 NOS.
Tree Planting
NUMBER OF TREES -160 NOS, TYPE/SPECIES- TABEBUIA ARGENTEA AND LAGERSTROEMIA FLOSRGINAE, SPACING -01 TREE PER 100 SQM OF OPEN AREA-MAINTENANCE PLAN-REGULAR MAINTENANCE BY GARDNER
Design For Electric Supply Including Street Lighting
30 NOS LIGHT POLE WITH LED LIGHT FIXTURE, TRANSFORMER (CSS) 2 X 1000+1X 1600 KVA
Community Buildings
NUMBER -01, AREA PER BUILDING -2575.79 SQM, CONSTRUCTION TYPE-RCC FRAMED WITH GLAZED FACADE, FACILITIES-HALL + GYM
Treatment and Disposal System of Sewage and Sullage water
STP CAP 370 KLD UNITS-ONE , TYPE OF STP- MBBR, TREATED WATER USE-IRRIGATION AND FLUSHING WATER.
Solid Waste Management And Disposal System
TOTAL 1.41 TPD (BIODEGRADABLE 0.66 TPD + NON-BIODEGRADABLE 0.75 TPD) MUNICIPAL SOLID WASTES GENERATED FROM THE PROJECT. THE WASTE WILL BE SEGREGATED INTO BIODEGRADABLE WASTE, NON-BIODEGRADABLE WASTE, PLASTIC WASTE , DOMESTIC HAZARDOUS WASTE AND HORTICULTURE WASTE IN SEPARATE BINS AS PER SOLID WASTE MANAGEMENT RULES, 2016. TH E BILDEGRADABLE WASTES WILL BE COMPOSTED IN ONSITE COMPOSTING UNIT AND THE MANURE WILL BE USED FOR LANDSCAPING. THE SEGREGATED NON-BIODEGRADABLE /RECYCLABLE WASTE WILL BE DISPOSED THROUGH AUTHORIZED VENDORS AS PER LOCAL NORMS.
Water Conservation System
RWH-05, SIZE -DESILTING TANK-2.5 x 1.75x 2.0m RECHARGE PIT -3.5x 1.75x 2.0m and AUTOMATIC RECHARGE AND EFFICIENT AS PER SOIL CONDITION.
Energy Management System Including Use of Renewable Energy
23 KW SOLAR PLANT , 46 NOS OF SOLAR PANEL, DG SET 1x 1010+ 2 x 500 KVA.
Fire Protection And Fire Safety System
HYDRANTS-200. FIRE PROTECTION AS PER CODE AND NBC. A COMPLETE FIRE SAFETY SYSTEM WITH A-GRADE MATERIALS WILL BE INSTALLED AS SPECIFIED IN THE UPFES GUIDELINES ,
Social Infrastructure And Other Public Amenities Including Public Health Services
NA
Emergency Evacuation Services
ALL EMERGENCY EVACUATIONSERVICES HAVE BEENARRANGED AS PER THE REQUREDNORMS, FIRE STAIRSCASE PROVIDED AS PER GUIDELINES OF (UPFES ) AND ALL THE GUIDELINES WILL BE STRICTLY FOLLOWED.
Other Miscellaneous Work
NA
Documents
Allotment Letter issued by Competent Authority
No: CHALLAN INSTALLMENT PAID TO AUTHORITY | Date:
Proforma of Completion Certificate(Occupancy)
Other
Permits
Project Team
Land Details
Showing 23 blocks with 502 units
Property Summary
Total Carpet Area
48639.67 m²
523552.54 ft²
Total Units
502
3 different types
Blocks & Floors
23
26 floors across all blocks
Parking
0
0 garages, 0 open
Block TOWER-A
96 unitsBlock TOWER-B
96 unitsBlock TOWER-D
96 unitsBlock TOWER-C
96 unitsBlock TOWER-E
100 unitsBlock SHOP-1
1 unitsBlock SHOP-2
1 unitsBlock SHOP-3
1 unitsBlock SHOP-4
1 unitsBlock SHOP-5
1 unitsBlock SHOP-6
1 unitsBlock SHOP-7
1 unitsBlock KIOSK-01
1 unitsBlock KIOSK-02
1 unitsBlock KIOSK-03
1 unitsBlock KIOSK-04
1 unitsBlock SHOP-8
1 unitsBlock SHOP-9
1 unitsBlock SHOP-10
1 unitsBlock SHOP-11
1 unitsBlock SHOP-12
1 unitsBlock SHOP-13
1 unitsBlock SHOP-14
1 unitsKhasra Details
Total Area
20235.00 m²
217807.52 ft²
