Launch Date
Completion Date
RERA ID
27.1925
78.340833333
234 plots are planned. After completing development works, each plot will be demarcated as per number plan before handed over to the allottee.
No provision of boundary wall in the scheme.
In addition of 45 M wide master plan road,1765 M length of 30 M wide , 1075 M 18 M wide and 660 m length of 12 m wide roads are planned. All roads are constructed with cement concrete of M-30 grade and cement concrete manufactured in automatic batching plant (RMC).
2.4 m wide footpath is planned in the park of the scheme.
Water supply to be done through 110 mm dia G.I. B- class pipe and Providing Tube well and 25000 litre capacity of Over head tank in the scheme.
Providing and laying non pressure NP-2 class R.C.C hume pipe of 300 mm dia. At present, there is no S.T.P nearby the scheme, so septic tank and soak pit shall be provided in the scheme.
Open drains are to be constructed in R.C.C. work with cement concrete in 1 1.5 3 (1 cement, 1.5 coarse sand and 3 stone grit 2 cm gauge)
Outer wall of park is to be constructed with class -150 brick work in 1 6 ( 1 cement and 6 coarse sand ) and footpath with interlocking tiles also shall be provided in the park.
1000 no of trees shall be planted in park area, central verge and sides of roads in the sceme.
Providing of 11/0433 KV 50 Hz outdoor type 3 nos of 250 KVA and 3 nos of 400 KVA is to be provided in the scheme.LT and HT line with steel tublur pole 9 meter long designated 410 SP-32, ACSR conductor shall be used. G.I. octagonal pole with ACSR conductor and 18 watt LED down lighter shall be used in Street light
Not required. Hence no provision is done in the layout plan.
There is no S.T.P. nearby the scheme so sewer disposal shall be done through septic tank and soak pit.
Solid waste is collected at site and cartage to the Nagar Nigam Firozabad dumping site and disposed off as per standard norms.
Rain water harvesting system shall be developed in the park area of the scheme.
Building Plans of Polts shall be sanctioned as per Provision of Building Bye laws for solar energy.
Not Required. hence no provision is made in the layout plan.
Provision of Two toilet blocks are made in layout plan.
45 M wide and 30 m wide roads are provided in the layout connecting to the old NH-2.
26194 sqm area is to be developed for parking. Common parking area, godown service area etc. is to be constructed with M-30 grade cement concrete and plot front parking area is to be constructed with interlocking tiles.
Showing 1 blocks with 4 units
Total Carpet Area
0.00 m²
0.00 ft²
Total Units
0
1 different types
Blocks & Floors
1
1 floors across all blocks
Parking
0
0 garages, 0 open
Total Area
137660.00 m²
1481758.47 ft²
