26.937919
80.909778
Plot is part of an approved existing township and is very well demarcated at site
2.5 mtr high boundary wall with fencing at top is proposed to be constructed
6.00 mtr wide CC road including 0.8 mt wide pathway is proposed as per the approved layout
paver blocks to be laid over sand base
All the drinking water supply to be through terrace tank of required capacity
A well laid sewer system connected to external sewer system is proposed. To be connected to township STP
open/under ground drains along internal roads
Well developed green spaces as per as approved layout. Play equipments, benches, shrubs and small plants shall be part of it.
4.5 to 6.0 mt trees along roads and inside green areas.
Electric design shall be with circulation areas and common facilities with generator backup. 25 percent of the shall have solar back up.
A small club with basic facilities.
All disposal shall lead to central STP provided for the whole Township
Shall be collected at one specific point. Final disposal tied up with Nagar Nigam.
A well designed Rain water harvesting is proposed to be constructed.
25 percent of the street lights shall have solar energy back up.
With reserve at ground and terrace level, connected to wet riser. Efficient fire alarm system with public address system on each floor.
This complex is part of an integrated residential township. all the basic amenities including health services are within 1.5 km distance.
All the fire exits and circulations are as per fire/NBC norms. Fire staircase has been provided
NA
Showing 2 blocks with 89 units
Total Area
8479.85 m²
91276.26 ft²
Total Units
98
3 different types
Blocks & Floors
2
12 floors across all blocks
Parking
0
0 garages, 0 open
Total Area
15730.00 m²
169316.15 ft²
