GAUR CHRYSALIS (PHASE 1)
Overview
Launch Date
Completion Date
Configurations
Sizes
Project Size
Total Floors
Launch Price
RERA ID
Basic Details
Location
28.281877
77.550299
Layout
Payment Plans
Floor Plan
Brochures
Walkthrough
Bank Details
Development Works
Demarcation of Plots
Demarcated the Complex having Plot area (Development plan area) of 37915.00 sq.mt. at Plot No. GH-12, Sector-22D, YEIDA, Situated in Greater Noida, G.B. Nagar (U.P.). This project is divided into two parts, Phase 1 and Phase 2. Now we will work on Phase 1 of this project whose area is 37915.00 sq.mt. which is mentioned in this development work list. In this plans of which has been approved by Yamuna Expressway Industrial Development Authority.
Boundary Wall
Well-defined plot boundaries proposed to ensure the security and privacy of the project. Development of the boundary wall (230 mm thickness of Concrete wall with minimum height of as per building Bye-Laws or design).
Road Work
Efficient road network for smooth connectivity between the various Housing Blocks within the project premises has been proposed as given in the Sanctioned site plan. Development of either Black-top roads (265 mm thick GSB - 100mm WMM under 100 MM, WBM - 40 MM and BC- 25MM thick bitumen material) or RCC Roads (Reinforced concrete having a minimum 100 MM thickness as designed) or Paver-roads.
Footpaths
Development of pathways for smooth pedestrian movement. Use of 60 mm to 80 mm thick Brick-type concrete/pavers and Grass pavers as per the design. Numbers of Crossing 18 Nos. (Annexure with development work plan, step 10.11).
Water Supply Including Drinking Water Facilities
Installation of water supply systems to ensure a steady and safe domestic water supply, including provisions for landscape water requirements. Use of HDPE pipe 200mm in Mainline, also UPVC and CPVC/GI pipe 15 MM to 80 MM as per the design requirements. Numbers of water connection 2 Nos. Tank capacity 200 KLD at the rate 4nos. Source of water by Municipal connection. (Annexure with water supply plan, step 10.9).
Sewer System
Development of a Sewerage System to collect wastewater generated within the project premises including treatment and disposal of wastewater/sewage. Use of pipe having dia. of 150 mm and above with adequate numbers of inspection Chambers and Man-Holes based upon the design and site requirements. Length of sewer lines 700mt. Concrete materials used in Construction of pipes, network design as per drawing. (Annexure with Sewerage layout plan, step 11.16).
Drain
Development of drainage systems within the site to manage surface water and storm water flow. In the Drainage System of the project, use of pipe having dia. of 200 mm and above and open Drains with adequate numbers of inspection Chambers and Man-Holes based upon the design and site requirements. Also using SN pipes of various grades as per the design. (Annexure with Drainage layout plan).
Parks
Development of landscape areas including green/ open spaces / recreational area / Tot-lots. Plantation of Shrubs besides planting Natural Grass and various water bodies, landscape features etc. as per the design. Use of Electrical poles having height of 4M in landscape areas.
Tree Planting
Planting 379 Trees of various types based upon the prevailing building regulations; predominantly along the boundary wall of the project as shown in the site plan. (Annexure with area chart).
Design For Electric Supply Including Street Lighting
Installation of Transformer capacity of 2000KVA, including street lighting, basement lighting etc. to ensure adequate illumination and safety at all the project common areas. Use of 6 M to 9 M height electrical poles, as per design and site requirements with LED Lights, Number of Electricals Poles 30 Nos. and Transformer units 5 Nos. (Annexure with Electricity supply Plan, Step 10.10).
Community Buildings
The Community Building of the project having total Built-up area of 7728.14 sq.mt. has been proposed under the Block-A of the Project at three levels i.e. Ground Floor, First Floor, and Second Floor; having various activities Halls, Meeting Rooms, Gym, Music and Art Room, Waterbody, several Games Court, Kids Play area, Yoga Area etc. details of the same are given in the approved building plans.
Treatment and Disposal System of Sewage and Sullage water
Provisions has been made for the installation of 1100 KLD STP to treat the sewage generated from the project and dispose of the surplus wastewater into the Municipal sewer line. (Annexure with sewerage layout plan, step 11.16).
Solid Waste Management And Disposal System
Provision of 700 Kg Capacity OWC Machine for Solid Waste management System to ensure proper collection, segregation, treatment and disposal of the solid waste as per the prevailing MSW Regulations.
Water Conservation System
It is a Green Building Group Housing Project which includes various measures for optimize use /conservation of water resources including Rainwater harvesting and dual banding system. The Flow rates of the proposed various Water Mixers including-Faucets/Taps, Sink, Showerhead/ Handheld Spray, Water Closets, Health Faucet etc. has been kept below normal flow rates for the project R.W.H 12 Nos. (Annexure with R.W.H layout plan).
Energy Management System Including Use of Renewable Energy
Proposed-Solar PV over the roof top of 275 KWP with use of high efficiency low energy consuming LED Lights. NBC 2016 of the relevant by laws of the concerned Local Authority, Basement ventilation with ventilation fans.
Fire Protection And Fire Safety System
As per fire drawings approved by the Fire department Installation of fire protection systems and safety measures to prevent and mitigate fire hazards as specified in the NBC-2016. Horizontal Riser of 150 mm or as per the design calculation, Vertical riser of 200 mm or as per the Design Calculation and Branches of 100 mm or as per the design calculation. M.S. C class pipe for 150 mm and below, M.S. pipe I.S. code for 200 mm and numbers of Hydrant 530 Nos. Fire exits 9 Nos. and number of Sprinkles 29500 Nos. all above with fire alarm and other safety measure as per requirement as per building Bye-Laws or design.
Social Infrastructure And Other Public Amenities Including Public Health Services
An emergency Evacuation Plan has been detailed out in the Environment Management Plan (EMP) in the EIA of the project which would be implemented with signage before completion of the project.
Emergency Evacuation Services
An emergency Evacuation Plan has been detailed out in the Environment Management Plan (EMP) of the project which would be implemented with signage before completion of the project.
Other Miscellaneous Work
As per the prevailing design/requirements including provisions for Earthquake Design Structures, Handicapped Friendly and CCTV units 10 Nos. in Building Design as per building Bye-Laws of YEIDA.
Documents
Proforma of Completion Certificate(Occupancy)
Permits
Project Team
Land Details
Showing 9 blocks with 965 units
Property Summary
Total Carpet Area
103468.12 m²
1113720.50 ft²
Total Units
952
3 different types
Blocks & Floors
9
36 floors across all blocks
Parking
0
0 garages, 0 open
Block B1/ARISTA
137 unitsBlock B2/AZURE
137 unitsBlock B3/CELESTE
137 unitsBlock B4/CIELO
137 unitsBlock B5/HELENA
137 unitsBlock B6/LUNA
137 unitsBlock B7/NOVA
137 unitsBlock Club- Orion
5 unitsBlock Prayer Hall
1 unitsKhasra Details
Total Area
37915.00 m²
408113.27 ft²
